PINARA 2 - Asymmetrical

  • Technical Specifications
  • LED
    350 - 500 - 700 mA (Nichia)
  • Gear
    Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request)
  • Cable
    0.5 m exiting top of fixture
  • Body
    Polycarbonate
  • Diffusers
    With clear or frosted tempered glass, without glass
  • Heatsing
    Aluminium extrusion profile
  • Springs
    Steel
The PINARA LED downlight is specially designed to deliver high output LED light with very clean beam angles to corridors, hotel rooms, museums and general lighting of public spaces. The Nichia LEDs in the PINARA are very efficient and have a high CRI (90). The unique lens that is used in this fixture creates very sharp beams that minimize the spill of uncontrolled light from the fixture. This reduces the glare of the fixture and gives more control to the architects and designers.

PRODUCT LIST & DOWNLOAD

  • Compare
    392131
    • Product Name
      PINARA 2
    • Power - Current
      10W - 350 mA
    • Color
      4000 K
    • Lumen
      1150 lm
    • Tilt
      Asymmetrical
    • LED
      350 - 500 - 700 mA (Nichia)
    • IP
      IP20
  • Compare
    392132
    • Product Name
      PINARA 2
    • Power - Current
      15W - 500 mA
    • Color
      4000 K
    • Lumen
      1600 lm
    • Tilt
      Asymmetrical
    • LED
      350 - 500 - 700 mA (Nichia)
    • IP
      IP20
  • Compare
    392133
    • Product Name
      PINARA 2
    • Power - Current
      21W - 700 mA
    • Color
      4000 K
    • Lumen
      2200 lm
    • Tilt
      Asymmetrical
    • LED
      350 - 500 - 700 mA (Nichia)
    • IP
      IP20
  • Compare
    PINARA 2
    • Product Name
      PINARA 2
    • Power - Current
      21W
    • Kelvin
      2700K
    • Color
      3000 K
    • Real Lumen Output
      1995 lm
    • Lumen
      1050 lm
    • Tilt
      Asymmetrical
    • LED
      350 - 500 - 700 mA (Nichia)
    • Voltage
      240 V A.C
    • IP
      IP20
  • Compare
    PINARA 2
    • Product Name
      PINARA 2
    • Power - Current
      21W
    • Kelvin
      3000K
    • Color
      3000 K
    • Real Lumen Output
      1995 lm
    • Lumen
      1500 lm
    • Tilt
      Asymmetrical
    • LED
      350 - 500 - 700 mA (Nichia)
    • Voltage
      240 V A.C
    • IP
      IP20
  • Compare
    PINARA 2
    • Product Name
      PINARA 2
    • Power - Current
      21W - 700 mA
    • Kelvin
      4000K
    • Color
      3000 K
    • Real Lumen Output
      2053 lm
    • Lumen
      2050 lm
    • Tilt
      Asymmetrical
    • LED
      350 - 500 - 700 mA (Nichia)
    • Voltage
      240 V A.C
    • IP
      IP20
